Plate Material: | 304/316/Ti Etc | Gasket Material: | EPDM/NBR/Viton/FKM Etc |
---|---|---|---|
Frame Material: | Carbon Steel | Model: | Free Solution Based On Your Request |
Color: | Blue Or OEM | HS Code: | 84195000 |
After-sale Service: | Online Support |
Stainless Steel AISI 316 Plate Heat Exchanger for Water Heating and Cooling,water to water parallel plate heat exchanger
Plate Heat Exchangers
welcome to inquiry us for plate heat exchanger,we supply plate heat exchanger based on your project work situation or Product drawing.
Standard materials
Hot water plate heat exchanger
Function of a Plate Heat Exchanger
A plate Heat Exchanger is a unit which transfers heat continuously from one media to another media without adding energy to the process. The basic concept of a plate and frame Heat Exchanger is two liquids flowing on either side of a thin corrugated metal plate so heat may be easily transferred between the two.
The plates are compressed by means of tie bolts between a stationary frame part (called the head) and a movable frame part (called the follower).
The plate Heat Exchanger efficiency requires less floor space compared to other types of Heat Transfer equipment and is lighter in weight.
Design of a Plate Heat Exchanger
The plate Heat Exchanger is designed with either single-pass or multi-pass flow, depending on the duty. For most duties single-pass is suitable and often the preferred solution as it keeps all connections on the stationary frame part and consequently makes disassembly easier. Multi-Pass however, is required when flow rates are low or when approach temperatures are close. Other factors such as building ceiling height or space limitations for handling of large plates often leads to the decision to use multi-pass and thereby more and smaller plates.
Advanges of Plate Heat Exchangers
Easy to Remove and Clean
Expandable
High Efficiency
Compact Size
Close Approach Temperature
Multiple Duties in a Single Unit
Less Fouling
Lower Costs
High performance for a low pressure drop eliminates unnecessary burdens on your system and optimizes overall system performance.
The design results in a compact solution with a small footprint, simple installation, and easy access for maintenance.
Plate material | Applicable fluids |
Stainless steel(SU304.316 ect) | Clean water, river water, edible oil, mineral oil |
Stainless steel & Ti, Ti-Pd | Sea water, salty water,salt compounds |
20Cr, 18Ni,SMO | Dilute sulfuric acid,Water solution of salt matter, Inorganic solution |
Nickel | High temperature and high concentration of caustic soda |
Hastelloy | Concentrated sulfuric acid,Hydrochloric acid, Phosphoric acid |
Sealing material: | adapt temperature | Suitable for fluid |
NBR | -15~+120ºC | Water, sea water, cooking oil, salt water |
HNBR | -15~+140ºC | High temperature mineral oil, high temperature water |
EPDM | -25~+170ºC | Hot water, water vapor, acid, alkali |
Viton | -5~+130ºC | Acid, alkali, fluid |
Function of a Plate Heat Exchanger
A plate Heat Exchanger is a unit which transfers heat continuously from one media to another media without adding energy to the process. The basic concept of a plate and frame Heat Exchanger is two liquids flowing on either side of a thin corrugated metal plate so heat may be easily transferred between the two.
The plate Heat Exchanger efficiency requires less floor space compared to other types of Heat Transfer equipment and is lighter in weight.
Design of a Plate Heat Exchanger
The plate Heat Exchanger is designed with either single-pass or multi-pass flow, depending on the duty. For most duties single-pass is suitable and often the preferred solution as it keeps all connections on the stationary frame part and consequently makes disassembly easier. Multi-Pass however, is required when flow rates are low or when approach temperatures are close. Other factors such as building ceiling height or space limitations for handling of large plates often leads to the decision to use multi-pass and thereby more and smaller plates.
Types of a Plate Heat Exchangers
Paraflow Plate Heat Exchangers
The Paraflow is the original plate type Heat Exchanger designed by APV to provide maximum efficiency and cost effectiveness in handling a wide variety of Heat Transfer applications.
ParaBrazed Plate Heat Exchangers
ParaBrazed Heat Exchangers are a compact, cost effective unit designed to deliver high thermal efficiency while maintaining lower pressure drops. It's the perfect choice for many single and two phase Heat Transfer applications for industrial and refrigeration duties.
Advanges of Plate Heat Exchangers
Easy to Remove and Clean
Expandable
High Efficiency
Compact Size
Close Approach Temperature
Multiple Duties in a Single Unit
Less Fouling
Lower Costs
Experience the benefit of an individually customized solution that perfectly matches your requirements and lowers your energy consumption.
High performance for a low pressure drop eliminates unnecessary burdens on your system and optimizes overall system performance.
The design results in a compact solution with a small footprint, simple installation, and easy access for maintenance.
